ADOT’s US 60 Pinto Creek Bridge replacement wins regional honor

ADOT’s US 60 Pinto Creek Bridge replacement wins regional honor

ADOT; AZDOT; Arizona Department of Transportation

PHOENIX – An Arizona Department of Transportation project that replaced the US 60 Pinto Creek Bridge between the East Valley and Globe has received a regional honor.

The 2023 America’s Transportation Awards named the effort Best Use of Technology and Innovation, Medium Project, for the Western region. The competition is sponsored by AASHTO, an association representing highway and transportation departments nationwide, as well as AAA and the U.S. Chamber of Commerce.

“We’re grateful to see the Pinto Creek Bridge replacement honored among projects throughout the West, but we’re even prouder of what this improvement has accomplished for those who rely on this critical route for passenger and commercial traffic,” said Greg Byres, ADOT State Engineer and Deputy Director for Transportation. “ADOT engineers and the contractor used innovative design and construction approaches to create a safer and more reliable US 60 for decades to come.”

Completed in 2022, the $25.3 million project built the new bridge next to the one it replaced, with traffic continuing to use the old bridge until the new bridge opened.

Among other innovative approaches used:

  • ADOT used a bid-alternative method for design, which allowed the contractor to determine economical and supportive foundation systems for each of the bridge’s three piers while taking into account the mountainous terrain.
  • To create retaining wall structures up to 30 feet high, ADOT engineers developed design standards and specifications for a micro-pile foundation system using high-strength, small-diameter steel rods.
  • A temporary access road was built to the floor of the steep canyon to provide access for heavy equipment, including a 400-ton crane that placed girders atop the piers, the tallest of which is 138 feet.
  • ADOT partnered with Desert Botanical Garden in Phoenix to temporarily remove and then return hedgehog cactuses unique to the project site.

You can view photos of the completed bridge at flic.kr/s/aHBqjzWgRb. Carrying two lanes of traffic, the bridge is 695.5 feet long, has 10-foot-wide shoulders and can carry heavier loads than its predecessor, which was 72 years old.

The award was presented last week at the annual meeting of WASHTO, which represents departments of transportation in the West.
